What is "Programmable oscillators"？

It is programmable oscillators using PLL, which can input and output any frequency that customer needs.
This programmable SPXO can be used in small lots and quick turn-around time for any frequency in the range of 1.2 MHz to 170 MHz, contributing to automotive applications from development to mass production.
Inputed oscillators can be used same as fundamental normal oscillators.

Click Here for details.

Advantages of Programmable SPXO

- Non-standard frequency
- Small-size lots
- quick lead time

Do you have any of these problems with SPXO?

What can be solved with Programmable SPXO

Recommended - SG8200 / SG8201 series

The SG-8200 and SG-8201series utilize Epson new low noise fractional-N PLL technology, where the stability has been improved by to 2x and phase jitter has been reduced 1/25th versus the previous generation of Epson programable crystal oscillator. It is ideal for variety of consumer and industrial applications, which requires small form factor and/or operation in harsh environment with wide operating temperature range up to +125°C. This programmable SPXO can be used in small lots and quick turn-around time for any frequency in the range of 1.2 MHz to 170 MHz, contributing to automotive applications from development to mass production.

Lineup of Epson Programmable SPXO

High operation temperature High accuracy & Low jitter "SG8200 / SG8201 series"

Programmable SPXO with high accuracy and low jitter. You can choose from 2 types; for general and for automotive.

Reduce EMI "SG-9101 series"

SG-9101 series are programmable SPXO with Spread Spectrum (SS) function to reduce EMI. You can choose from 2 types; for general and for automotive.

Automotive series

Epson automotive programmable SPXO utilize in-house IC and compliant to AEC-Q100. You can choose from some features, high accuracy, with spread spectrum.

Programmable SPXO Product List

Automotive	Recomm endation	Model	Size [ mm ]	Output Wave	Supply Voltage [ V ]	Output Frequency Range [ MHz ]	Frequency Tolerance [ x10^-6 ]	Operating Temperature Range [ ℃ ]	Note	Inventory
	A	SG-8200CJ	2.0 x 1.6 x 0.6	CMOS	1.8 2.5 3.3	1.2 to 170	±50	-40 to +125
	A	SG-8200CG	2.5 x 2.0 x 0.74	CMOS	1.8 2.5 3.3	1.2 to 170	±50	-40 to +125
	A	SG-8201CJ	2.0 x 1.6 x 0.6	CMOS	1.8 2.5 3.3	1.2 to 170	±15 ±25	-40 to +105 -40 to +125
	A	SG-8201CG	2.5 x 2.0 x 0.74	CMOS	1.8 2.5 3.3	1.2 to 170	±15 ±25	-40 to +105 -40 to +125
AEC-Q100	A	SG-8201CJA	2.0 x 1.6 x 0.6	CMOS	1.8 2.5 3.3	1.2 to 170	±15	-40 to +105		Contact us
							±25	-40 to +125
							±50	-40 to +125
	A	SG-8018CA	7.0 x 5.0 x 1.3	CMOS	1.8 2.5 3.3	0.67 to 170	±50	-40 to +105
		SG-8018CB	5.0 x 3.2 x 1.1
		SG-8018CE	3.2 x 2.5 x 1.05
		SG-8018CG	2.5 x 2.0 x 0.7
	A	SG-8101CA	7.0 x 5.0 x 1.3	CMOS	1.8 2.5 3.3	0.67 to 170	±15 ±20 ±50	-40 to +85 -40 to +105 -40 to +105
		SG-8101CB	5.0 x 3.2 x 1.1
		SG-8101CE	3.2 x 2.5 x 1.05
		SG-8101CG	2.5 x 2.0 x 0.7
AEC-Q100		SG-8101CGA	2.5 x 2.0 x 0.7	CMOS	1.8 2.5 3.3	0.67 to 170	±15	-40 to +85		Contact us
							±20	-40 to +105
							±50	-40 to +125
							±100	-40 to +125
	A	SG-8503CA	7.0 x 5.0 x 1.5	LV-PECL	2.5 3.3	50 to 800	±31.5	-40 to +85	Dual Selectable
	A	SG-8503CA	7.0 x 5.0 x 1.5	LV-PECL	2.5 3.3	50 to 800	±50	-40 to +85	Dual Selectable
	A	SG-8504CA	7.0 x 5.0 x 1.5	LV-PECL	2.5 3.3	50 to 800	±31.5	-40 to +85	Quad Selectable
	A	SG-8504CA	7.0 x 5.0 x 1.5	LV-PECL	2.5 3.3	50 to 800	±50	-40 to +85	Quad Selectable
	A	SG-8506CA	7.0 x 5.0 x 1.5	LV-PECL	2.5 3.3	50 to 800	±31.5	-40 to +85	I²C-Bus
	A	SG-8506CA	7.0 x 5.0 x 1.5	LV-PECL	2.5 3.3	50 to 800	±50	-40 to +85	I²C-Bus
		SG-WriterII							Q91PR20W11020

Spread Spectrum Programmable XO

Automotive	Recomm endation	Model	Size [ mm ]	Output Frequency Range [ MHz ]	Operating Temperature Range [ ℃ ]	Supply Voltage [ V ]	Output Wave	Spread Type1	Spread Type2	Spread Range1 [ % ]	Spread Range2 [ % ]	Inventory
	A	SG-9101CA	7.0 x 5.0 x 1.3	0.67 to 170	-40 to +85 -40 to +105	1.8 2.5 3.3	CMOS	Center Spread	Down Spread	±0.25 ±0.5 ±0.75 ±1.0 ±1.5 ±2.0	-0.5 -1.0 -1.5 -2.0 -3.0 -4.0
		SG-9101CB	5.0 x 3.2 x 1.1
		SG-9101CE	3.2 x 2.5 x 1.05
		SG-9101CG	2.5 x 2.0 x 0.7
AEC-Q100	A	SG-9101CGA	CG : 2.5 x 2.0 x 0.7	0.67 to 170	-40 to +125	1.8 2.5 3.3	CMOS	Center Spread	Down Spread	±0.25 ±0.5 ±0.75 ±1.0 ±1.5 ±2.0	-0.5 -1.0 -1.5 -2.0 -3.0 -4.0	Contact us
